Product Type Features
- Performance Category = Cat 5e
- Series = Standard
- Cable Style = Simplex
- Wire/Cable Type = Twisted Pair
- Shield Type = Overall Foil
- Shielded = Yes
Electrical Specifications
- Operating Voltage, maximum: 80 V
- Remote Powering: Fully complies with the recommendations set forth by IEEE 802.3bt (Type 4) for the safe delivery of power over LAN cable when installed according to ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2 or TIA TSB-184-A
- Safety Voltage Rating: 40 V
Material Specifications
- Conductor Material: Bare copper
- Insulation Material: Polyolefin
- Jacket Material: Low Smoke Zero Halogen (LSZH)
- Shield (Tape) Material: Aluminum/Polyester
Environmental Specifications
- Operating Temperature: -20 °C to +60 °C (-4 °F to +140 °F)
Termination Features
- Wire/Cable Size (AWG) = 24
- Cable Outer Diameter (mm [in]) = 6.20 [0.244]
- Length (M [ft]) = 305.00 [1001.00]
- Jacket Color = White
- Number of Twisted Pairs = 4
- Cable Configuration = F/UTP (Foiled/Unshielded Twisted Pair)
Industry Standards
- Flammability Rating Type = LSZH (Low Smoke Zero Halogen)
- RoHS/ELV Compliance = RoHS compliant, ELV compliant
- Lead Free Solder Processes = Not relevant for lead free process
- RoHS/ELV Compliance History = Always was RoHS compliant
Packaging Features
- Packaging Method = Pull Box
Product Availability
- Region = EMEA
Other
- Brand = Madison Cable
| Тегло, кг | 0.000000 |
|---|---|
| Марка | COMMSCOPE |
| Цвят | Бял |
| Екраниран | ДА |
| Екранировка | F/UTP |
| Категория кабел | кат. 5e |
| AWG-size | 24 |
| Jacket type | LSZH |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
