Electrical Characteristics:
- Max Attenuation @ 1310nm (dB/km) = 0.45
- Max Attenuation @ 1550nm (dB/km) = 0.35
- Fiber Type (Micron) = OS2 9/125
- Length (M [ft]) = 1000.00 [3280.80]
- Installation Bend Radius (mm [in]) = 200.00 [7.870]
- Armoring = Corrugated Steel
- Cable Construction = 1 x 12
- Cable Color = Black
- Nominal Outside Diameter (mm [in]) = 10.00 [0.394]
- Long Term Bend Radius (mm [in]) = 160 [6.3]
- Nominal Weight (kg/km) = 104
- Long Term Tensile Strength (Newton [lbf]) = 1250.0 [281]
- Number of Fibers = 12
- Cable Buffering = Loose Tube - Gel
Industry Standards:
- Flammability Rating Type = HDPE (High Density Poly Ethylene)
- RoHS/ELV Compliance = RoHS compliant, ELV compliant
- Lead Free Solder Processes = Not relevant for lead free process
- RoHS/ELV Compliance History = Always was RoHS compliant
Environmental:
- Operating Temperature (°C [°F]) = -20 – +70 [-4 – +158]
Operation/Application:
- Application = Outdoor
Product Availability:
- Region = EMEA, Australia/New Zealand
Other:
- Brand = TE Connectivity
