Mechanical Attachment:
- Installation Tensile Strength (Newton [lbf]) = 1250.0 [281]
- Max Attenuation @ 850nm (dB/km) = 3.5
- Max Attenuation @ 1300nm (dB/km) = 1
- Fiber Type (Micron) = OM3 50/125
- Length (M [ft]) = 1000.00 [3280.80]
- Installation Bend Radius (mm [in]) = 130.00 [5.120]
- Armoring = None
- Cable Construction = 1 x 12
- Cable Color = Aqua
- Nominal Outside Diameter (mm [in]) = 6.40 [0.251]
- Long Term Bend Radius (mm [in]) = 80 [3.15]
- Nominal Weight (kg/km) = 48
- Long Term Tensile Strength (Newton [lbf]) = 650.0 [146]
- Number of Fibers = 12
- Cable Buffering = Loose Tube - Gel
Industry Standards:
- Flammability Rating Type = ULSZH (Universal Low Smoke Zero Halogen)
- RoHS/ELV Compliance = RoHS compliant, ELV compliant
- Lead Free Solder Processes = Not relevant for lead free process
- RoHS/ELV Compliance History = Always was RoHS compliant
Environmental:
- Operating Temperature (°C [°F]) = -20 – +70 [-4 – +158]
Operation/Application:
- Application = Indoor, Indoor/Outdoor, Outdoor
Product Availability:
- Region = EMEA, Australia/New Zealand
Other:
- Brand = TE Connectivity
| Тегло, кг | 0.000000 |
|---|---|
| Марка | COMMSCOPE |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
