Features
- HDMI receiver compatible with HDMI 1.4 specification
- Supported resolution up to WUXGA 1920x1200 @ 60Hz and 1920x1080 @ 60Hz
- Analog output RGB to VGA triple 9-bit DAC up to 200MHz pixel
- Synchronization signals can be supplied separately or composite
- Support VESA and CEA Standard timing
- Audio encoder which supports 2-channel IIS / S / PDIF audio output
- VGA output is compatible with VESA VSIS V1R2
- MCU integrated to manage the control logic
- Support device winding firmware from flash memory Boot ROM
- Buffer Integrated EDID
- Auto Power saving and low power consumption in stand-by
- Support YCC to RGB conversion in ITU-R BT.601 color space and 709
- Plug & Play: installs in seconds, without any changes required
- Converts digital HDMI signal into analog VGA video
- Supports HDCP 1.0 / 1.1 / 1.2
- Cable length: 15 cm
- Compact design
- Black color
Connections
- Input: HDMI A Male (19 pin)
- Output: VGA Female
- Audio port 3.5" female
- HDMI input: 480I / 576I / 480P / 576P / 720P / 1080I / 1080P / 1200
- VGA output: 480I / 576I / 480P / 576P / 720P / 1080I / 1080P / 1200
Applications
- Notebook / Ultrabook
- Tablet
- PDA / handheld devices
- Digital video systems
Environmental Characteristics
- Operating Temperature: 0 ° to + 70 ° C
- Operating Humidity: 10% to 85% RH (non-condensing)
- Storage Temperature: -10 ° to + 80 ° C
- Storage Humidity: 5% to 95% RH (non-condensing)
Certifications
- CE
- FCC
- RoHS
- WEEE
Package Contents
- HDMI converter cable IDATA-VGA2A
- Audio Cable 1 m
- Instruction Manual
| Тегло, кг | 0.000000 |
|---|---|
| Марка | Techly |
| Цвят | Черен |
| Вид кабел | HDMI |
| Тип | Кабел, Преходник |
| За пренос на | Аудио сигнал, Видео сигнал, Данни |
| Вид конектор - КОМПЮТЪРЕН | HDMI Standard, VGA |
| Дължина на кабела | 3.5 мм |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0 |
