Body Features
- Jacket Material: LSZH
- Cable Configuration: F/FTP
- Jacket Color: White
- Cable Construction: 4 x 2
- Cable Weight: 48.5 kg/km
- Conductor Material: Solid bare copper
- Insulation Material: Polyethylene
- Shield Material: Aluminum
- Shield Type: Individual foiled pairs/Overall foil
Configuration Features
- Number of Pairs: 4
Dimensions
- Overall Outside Diameter: 7.000 mm | 0.276 in
- Length: 500.00 m | 1640.42 ft
- Wire Size (CMA): 23 AWG
Environmental Specifications
- Operating Temperature: -20 °C to +60 °C (-4 °F to +140 °F)
Electrical Specifications
- ANSI/TIA Category: 6A
- Nominal Velocity of Propagation (NVP): 79 %
- Transmission Standards: ANSI/TIA-568-C.2 | CENELEC EN 50288-6-1 | ISO/IEC 11801 Class E
Industry Standards
- Flammability Rating IEC 60332-1-2
| Тегло, кг | 0.000000 |
|---|---|
| Марка | COMMSCOPE |
| Цвят | Бял |
| Екраниран | ДА |
| Екранировка | F/FTP |
| Категория кабел | кат. 6a |
| AWG-size | 23 |
| Jacket type | LSZH |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
