- Support CW and 2Hz modulation work mode.
- Solid: use special laser end design to avoid damage when dropping on the floor.
- Long working hours: use effective laser drive circuit to ensure 1mW/650nm locator can work more than 50 hours continuously.
- Stable power output: use special laser driver circuit, which can ensure stable power output in the low battery.
- 2.5 mm universal adapter: use 2.5 mm universal adapter, can match SC, FC, ST adapters.
SPECIFICATIONS
|
Type |
TC-10-1 |
TC-10-10 |
TC-10-20 |
TC-10-30 |
TC-10-50 |
|
Output Power |
>1mw |
>10mw |
>20mw |
>30mw |
>50mw |
|
Dynamic Range |
>5km |
>10km |
>18km |
>20km |
30km~40km |
|
Wavelength |
650nm±20nm |
||||
|
Light source |
LD laser |
||||
|
Connector |
2.5 mm universal adapter |
||||
|
Working mode |
CW or 2Hz modulation |
||||
|
Operating temperature |
-10 ~ +50 °C |
||||
|
Storage temperature |
-20 ~ +60 °C |
||||
|
Power |
2pcs AA battery |
||||
|
Working hours |
≥ 50 (1mW) |
||||
|
Weight |
78g (excluding batteries) |
||||
|
Dimension (mm) |
|
||||
|
Packaging Size (mm) |
210*73*30 |
||||
| Тегло, кг | 0.000000 |
|---|---|
| Цвят | Черен |
| Country of Manufacture | Китай |
| Изходяща мощност | 10 mW |
| Дължина на вълната, nm (дублиран) | 650 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
