Main Functions
Automatic Measurement Mode: Operators don’t need to choose the test distance and pulse width, the tester will automatically judge the length and choose suitable dynamic range as well as pulse width to complete the work; the storage of event trace can be saved manually or automatically.
Multiple Wavelengths Measurement Mode: In order to use different wavelengths to execute the loss calculation in one fiber, we can choose duplex wavelengths test mode from parameter settings, the tester will switch wavelengths automatically.
Multiple Trace Analysis: Simultaneously display 4 traces, operators can compare the traces and make analysis of any ones among the traces.
Duplex Operation Mode: Pure operation via touch screen or pure operation via the pressing keys.
Typical Events
Precision judgment of fiber faults; splicing posit and connector terminal.
Precision measurement of test distance and the fiber loss.
Contracted design style, lively graphical interface, easy operation and easy analysis of various events.
Measure the length of whole fiber; length between two points, as well as the distance, loss and attenuation coefficient etc.
Detailed description of fiber loss distribution curve and the events.
| Тегло, кг | 0.000000 |
|---|---|
| Изходяща мощност | 10 mW |
| Дължина на вълната, nm (дублиран) | 1550, 1310 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
