- Category: 6
- Type of connector connection 1: RJ45 8(8)
- Type of connector connection 2: RJ45 8(8)
- Connector type: RJ45 Standard
- Contacts: Gold plated
- Pin assignment: 1:1
- Allocation: acc. TIA/EIA 568B
- Type: Shielded
- Length imprint: Yes
- Anti-kink sleeve: Moulded
- Color anti-kink sleeve: Purple/violet
- Locking lever: Yes
- Mating cycles: ≥750
- Bending radius: >31 mm
- Conductive shield: Selected shield contact
- Cable structure: S/FTP
- Cable construction: 4x2
- AWG-size/strands per core: 27/7
- Conductor Material: Copper
- Silicone-free: Yes
- Jacket material: LSZH
- Color outer sheath: Magenta
- Outer diameter of the cable: 6.2 mm
- Flame-retardant: acc. IEC60332-1
- Halogen-free: Yes
- Low smoke: Yes
- Temperature range: 0 – 60 °C
- NVP value: - %
- Conductor resistance DC: 185 Ω/km
- Loop resistance: 370 Ω/km
- Resistance unbalance: 5 %
- Insulation resistance: 10 MΩ
- Contact resistance: 30 mΩ
- POE class: PoE acc. to IEEE802.3af;PoE+ acc. to IEEE802.3at;4PPoE acc. to IEEE802.3bt
- Bandwidth: 250MHz
- Connector: IEC 60603-7-5
| Тегло, кг | 0.000000 |
|---|---|
| Марка | EFB Elektronik |
| Цвят | Розов |
| Екраниран | ДА |
| Екранировка | S/FTP |
| Категория кабел | кат. 6 |
| Вид конектор - КОМПЮТЪРЕН | RJ45 |
| AWG-size | 27 |
| Jacket type | LSZH |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
