- Category: 6A (TIA)
- Type of connector connection 1: RJ45 8(8)
- Type of connector connection 2: RJ45 8(8)
- Connector type: RJ45 short version
- Contacts: Gold plated
- Pin assignment: 1:1
- Allocation: acc. TIA/EIA 568B
- Type: Shielded
- Anti-kink sleeve: Moulded
- Color anti-kink sleeve: Black
- Locking lever: Yes
- Mating cycles: ≥750
- Bending radius: >20 mm
- Conductive shield: Selected shield contact
- Cable structure: U/FTP
- Cable construction: 4x2
- AWG-size/strands per core: 30/7
- Conductor Material: Copper
- Silicone-free: Yes
- Jacket material: PVC
- Color outer sheath: Black
- Outer diameter of the cable: 7.0*2.2 mm
- Temperature range: -20 – 55 °C
- NVP value: 76 %
- Impedance: 100 ±15 Ω
- Conductor resistance DC: 376 Ω/km
- Loop resistance: 752 Ω/km
- Resistance unbalance: <4 %
- Insulation resistance: 100 MΩ
- Test voltage: 1000 (V DC, 1min) core/core und core/screen
- POE class: PoE acc. to IEEE802.3af;PoE+ acc. to IEEE802.3at;4PPoE acc. to IEEE802.3bt
- Bandwidth: 500MHz
- Connector: IEC 60603-7-51
| Тегло, кг | 0.000000 |
|---|---|
| Марка | EFB Elektronik |
| Цвят | Черен |
| Екраниран | ДА |
| Екранировка | U/FTP |
| Категория кабел | кат. 6a |
| Вид конектор - КОМПЮТЪРЕН | RJ45 |
| AWG-size | 30 |
| Jacket type | PVC |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
