Features
- Supports HDMI 2.0 4K 60Hz
- Supports 3D video format
- HDCP 1.4 and 2.2 compliant
- Maximum video resolution up to 3840 x 2160 / 60Hz
- Maximum frequency 18G; the TMDS clock can go up to 600 MHz
- Supports 8/10/12/16 bit deep color
- Using standard AWG26 cable, the transmission distance can reach 40 meters (3840 x 2160/ 30Hz)
Technical specifications
- HDMI resolution up to 3840*2160/60Hz
- Video format supported 8/10/12/16 bit Deep Color
- Supported audio format DTS HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
- Maximum bandwidth 600 MHz
- Maximum transmission speed: 3 x 6 Gbps
- Cable Distance: Input 5 m, Output 5 m (4K@60Hz), Input 20 m, Output 20 m (4K@30Hz/1080p)
- Supports RGB 4:4:4 / YCbCr 4:4:4 / YCbCr 4:2:2 / YCbCr 4:2:0
- Maximum current during operation: 300 mA
Environmental characteristics
- Operating temperature: from -15°C to 55°C
- H
| Тегло, кг | 0.000000 |
|---|---|
| Марка | Techly |
| Цвят | Черен |
| Тип | Удължител |
| За пренос на | Аудио сигнал, Видео сигнал, Данни |
| Стандарт | HDMI 2.0 |
| Вид конектор - КОМПЮТЪРЕН | HDMI Standard |
| AWG-size | 26 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
