Features
- Supporting 802.3, 802.u Faster Ethernet, IEEE 802.3ab 1000BASE-T
- Supports POE IEEE 802.3af/at compliant Powered Device (PD)
- Modes: Normal switch mode/Extended mode (Port1-8: 250 meters ultra-long transmission)
- Ports 1~8 features POE power supply capability and can be used as Power over Ethernet devices；2x10/100/1000Base-T Uplink and 1x1000Base-X SFP
- Support full duplex based on IEEE802.3x and half duplex based on Backpressure
- Auto MDI/MDIX crossover for all ports
- Support non-blocking wire speed forwarding
- MAC address auto-learning & auto-aging
- Steel case, the total POE power budget of 100W
- Just Plug and Play
Specifications
- Interface: 8x10/100Mbps POE ports (Data/Power); 2x10/100/1000M uplink RJ45 ports (Data)
- Mode: Normal switch mode/Extend mode
- Data Transfer Rate: Ethernet: 10Mbps (Half-duplex); 20Mbps (Full-duplex); Fast Ethernet: 100Mbps (Half-duplex); 200Mbps (Full-duplex); Gigabit Ethernet: 2000Mbps (Full-duplex)
- Power Input POE Standards: Single port maximum power 30W, Whole switch maximum power 100W; Support over-current, over-voltage and short-circuit protection; Support Soft Start of High Power PD; Support sequential boot-up; Power Supply Pin: 12+/36-; AC 110~240V 50/60HZ
- Cabling type: 100Base-TX: Cat 5e or better UTP/STP (≤100 m); 10Base-TX: Cat 5e or better UTP/STP (≤250 m)
- Dimensions (L x W x H ): 190 x 140 x 43 mm
- Operation Temperature: 0℃～40℃
- Storage Temperature: -40℃～70℃
- Operation Humidity: 10%～90% RH Non-condensing
- Storage Humidity: 5%～90% RH Non-condensing
| Тегло, кг | 0.000000 |
|---|---|
| Марка | STONET |
| Цвят | Черен |
| Country of Manufacture | Китай |
| Вид Лан Портове | 10/100 Mb/s RJ45, 10/100/1000 Mb/s RJ45 |
| Брой Лан Портове | 10 |
| Оптични портове | SFP |
| Брой Оптични Портове | 1 |
| Скорост оптични портове | 100 Mb/s, 1 Gb/s |
| PoE | ДА |
| PoE Стандарт | IEEE 802.3af 15.4W PoE, IEEE 802.3at 30W PoE+ |
| Приложение: | Commercial |
| Управление на суичовете | Неуправляем |
| Form Factor | Десктоп |
