Serial Interface
- One DB9 interface supports RS232, 2-wire RS485, 4-wire RS485 and RS422 operation
- Asynchronous serial data rates up to 921600bps
- Data mode includes VCOM, RFC2217, TCP Server, TCP Client, UDP, Remote Pair, Modbus converter server / client and Serial Telnet modes
Ethernet Port
- 1-port 100BASE-FX SFP slot
Management
- IPv4 and IPv6 dual stack management
- Remote Management Interfaces: IP-based Web management; Telnet console management; Windows-based VCOM utility supports searching, monitoring and configuration setting
- IP NTP (Network Time Protocol)
- Standard TCP/IP interface and versatile operation modes
- Software Protocol supports ICMP, TCP/IP, UDP, HTTP server, DHCP client, Telnet server/client
- Serial Operation mode selected via management interface
- Pair Connection mode for connecting two serial devices over a network
- Allows a maximum of 4 hosts to be accessed as TCP client mode
- Firmware upgrade via HTTP protocol
- Accessible IP security control to prevent illegal users
- Event notification: Remote syslog server; SNMP trap
- DHCP client for IP address assignment
- PLANET Smart Discovery utility automatically finds the client devices on the network
Case and Installation
- Compact size for easy Installation
- Standalone - Wall mountable or DIN-rail mounting (optional accessory)
- Co-works with PLANET MC family Media Chassis (MC-700/1500)
- External power adaptor 5V DC, 2A max.
- Supports 6000 VDC Ethernet ESD protection
- 10 to 60 degrees C operating temperature
- Supports extensive LED indicators for network diagnosis
- Reset button for resetting to factory default
| Тегло, кг | 0.000000 |
|---|---|
| Марка | Planet - Тайван |
| Цвят | Черен |
| Country of Manufacture | Тайван |
| Form Factor | За монтаж в шкаф, За монтаж на DIN шина |
| Вид конектор - КОМПЮТЪРЕН | RS232 |
| Приложение: | Commercial |
| Вид конектор - ОПТИЧЕН | SFP |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
