Physical Ports
- 24 10/100/1000BASE-T RJ45 copper ports
- 4 10GBASE-SR/LR SFP+ slots, backward compatible with 1000BASE-SX/LX/BX SFP
- RJ45 to DB9 console interface for switch basic management and setup
Layer 2 Features
- 16K MAC address table, automatic source address learning and aging
- Supports VLAN
- Supports Link Aggregation
- Supports Spanning Tree Protocol
- Port mirroring to monitor the incoming or outgoing traffic on a particular port (one-to-one and many-to-one)
- Provides port mirror (many-to-1)
- Supports G.8032 ERPS (Ethernet Ring Protection Switching)
- Loop protection to avoid broadcast loops
- Link Layer Discovery Protocol (LLDP)
- Compatible with Cisco UDLD (uni-directional link detection) that monitors a link between two switches and blocks the ports on both ends of the link if the link fails at any point between the two devices
Quality of Service
- 8 priority queues on all switch ports
- Support for strict priority and WRR (Weighted Round Robin) CoS policies
- Traffic classification: IEEE 802.1p CoS/ToS; IPv4/IPv6 DSCP; Port-based WRR
- Strict priority and WRR CoS policies
Management
- IPv4 and IPv6 dual stack management
- Switch Management Interface
- Console and Telnet Command Line Interface
- HTTP Web switch management
- SNMP v1 and v2c switch management
- SSHv1/v2, TLSv1.2 and SNMPv3 secure access
- SNMP Management
- Four RMON groups 1, 2, 3, 9 (history, statistics, alarms and events)
- SNMP trap for interface Link Up and Link Down notification
- BOOTP and DHCP for IP address assignment
- System Maintenance
- Firmware upload/download via TFTP or HTTP Protocol for IPv4 and IPv6
- SNTP (Simple Network Time Protocol) for IPv4 and IPv6
- User privilege levels control
- Syslog server for IPv4 and IPv6
- Supports sFlow
- DHCP Functions
- DHCP Option82
- DHCP server/relay/client
- Network Diagnostic
- Supports ping, traceroute function for IPv4 and IPv6
- Supports DDM (Digital Diagnostic Monitor)
- Supports ISSU (In-service Software Upgrade) to guaranteeing non-stop user data transmission when the system is upgraded.
| Тегло, кг | 0.000000 |
|---|---|
| Марка | Planet - Тайван |
| Цвят | Син |
| Country of Manufacture | Тайван |
| Брой RJ45 портове | 24 |
| Приложение: | Commercial |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
