- AWG-size: 24/7
- Allocation: acc. TIA/EIA 568B
- Anti-kink sleeve: plugged in
- Area of Application: Structured cabling; Data center
- Bandwidth: 500MHz
- Bending radius: 30 mm
- Cable construction: 4x2
- Cable type: U/UTP
- Cabling standard: ISO/IEC 11801;EN50173
- Category: 6A (TIA)
- Colour anti-kink sleeve: white
- Colour outer sheath: white
- Conductor Material: Copper
- Connector: IEC 60603-7-41
- Connector type: RJ45 Standard blue
- Contacts: 50 µ" gold plated
- Current Rating: max. 1 A
- Fire retardant version: Yes
- Flame retardant: acc. IEC60332-1
- Halogen-free: Yes
- Halogen free: Yes
- Locking lever: Yes
- Low smoke: Yes
- Material outer sheath: LSZH
- Mating cycles: 2000
- Model: Unshielded
- NVP value: - %
- Oil resistant (acc. EN 60811-2-1): No
- Oil resistant (according to EN 60811-404): Yes
- Operating-/ tempering voltage: max. 50 V DC
- Outer diameter of the cable: 6.0 mm
- POE class: PoE acc. to IEEE802.3af; PoE+ acc. to IEEE802.3at; 4PPoE acc. to IEEE802.3bt
- Pin assignment: 1:1
- Printing: Cat. 6A PREMIUM Patch cord U/UTP 4x2xAWG24/7 ISO/IEC11801 TIA/EIA-568-C.2 ***10Gigabit Ethernet***
- Suitable for degree of protection (IP): IP20
- Temperature range: 0 – 60 °C
- Transmission: 10Gbit
- Type of connector connection 1: RJ45 8(8)
- Type of connector connection 2: RJ45 8(8)
| Тегло, кг | 0.000000 |
|---|---|
| Марка | EFB Elektronik |
| Цвят | Бял |
| Екраниран | НЕ |
| Екранировка | U/UTP |
| Категория кабел | кат. 6a |
| Вид конектор - КОМПЮТЪРЕН | RJ45 |
| AWG-size | 24 |
| Jacket type | LSZH |
| Клас на защита | IP 20 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
