Hardware
- Main chip: MTK, 450Mbps High Performance Enterprise Chip
- Frequency: 560MHz
- Wireless technology: 5G, 450M, 802.11ac MIMO technology
- Memory: 64MB DDR RAM
- Flash: 8MB
- Network interface: 2*10/100Mbps Adaptive Network Interface
- Button: 1*Reset, Press and hold for 15 seconds to restore factory settings
- Indicator light: Signal SIG indicator, ETH network interface status indicator, power indicator lamp, digital tube indicator lamp.
- Power supply: 24V 0.5A non-standard POE power supply, DC 12V 1A, power consumption <10W
- Working conditions: Temperature: -40°C～+55°C (work), -40°C～+70°C (сtorage)/ Humidity (non-condensing): 5% to 90% (working), 5% to 95% (storage)
- Product size: Length 188 mm*Width 188 mm*Height 33 mm
- Product weight: N/A
- Antenna: Built-in dual polarized high gain directional antenna (14dBi plate wave angle of 60 degrees, 60 degrees vertical wave width)
Radio frequency characteristics
- Frequency Range: ISM band: 4.900GHz ~ 5.850GHz
- Channel distribution: 5G: 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 182, 186, 190, 194
- Modulation method: OFDM = BPSK, QPSK, 16-QAM, 64-QAM; DSSS = DBPSK, DQPSK, CCK
- Output Power: 11a @54M:25±2DB, @6M:27±2DB/ 11n @MCS7:23±2DB, @MCS0:25±2DB
- Receiver sensitivity: 11a: 72dbm@54Mbps, -90dbm@6Mbps/ 11n: -70dbm@MCS7, -90dbm@MCS0s
- EVM: 802.11n: ≤-28 DB, 802.11a: ≤-25 DB
- Frequency deviation: ±20ppm
Fat AP version software features
- Operating mode: Main AP mode, Slave AP mode
- Networking mode: Point to point and point to multipoint (within 8 points)
- Management method: Chinese WEB remote management
- Internet: Bridge: static IP/ DHCP, Gateway: static IP/ DHCP/ PPPoE
- Bridge Management: Free binding cloud account, real-time remote management device
- Wireless management: Bridge configuration, advanced configuration, WiFi settings
- System: Time zone time configuration, login password modification, backup/ restore, restart/ timed restart
- System update: Based on WEB browser local update, online update
| Тегло, кг | 0.000000 |
|---|---|
| Марка | STONET |
| Цвят | Бял |
| Country of Manufacture | Китай |
| Вид Лан Портове | 10/100 Mb/s RJ45 |
| Брой RJ45 портове | 2 |
| WiFi Скорост | N450 |
| WiFi Стандарт | 802.11ac |
| Клас на защита | IP 65 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
