- AWG-size: 24/7
- Allocation: acc. TIA/EIA 568B
- Anti-kink sleeve: plugged in
- Area of Application: Data center, Industrial Ethernet, Structured cabling
- Bandwidth: 250MHz
- Bending radius: 30 mm
- Cable construction: 4x2
- Cable type: U/UTP
- Cabling standard: EN50173, ISO/IEC 11801
- Category: 6
- Colour anti-kink sleeve: grey
- Colour outer sheath: grey
- Conductor Material: CCA
- Connector: IEC 60603-7-4
- Connector type: RJ45 Standard
- Contacts: Gold plated µ" gold plated
- Current Rating: max. 1 A
- Fire retardant version: True
- Flame retardant: True
- Halogen-free: True
- Halogen free: True
- Locking lever: True
- Low smoke: True
- Material outer sheath: LSZH
- Mating cycles: ≥750
- Model: Unshielded
- NVP value: - %
- Oil resistant (acc. EN 60811-2-1): False
- Oil resistant (according to EN 60811-404): False
- Operating-/ tempering voltage: max. 50 V DC
- Outer diameter of the cable: 5.9 mm
- POE class: 4PPoE acc. to IEEE802.3bt, PoE+ acc. to IEEE802.3at, PoE acc. to IEEE802.3af
- Pin assignment: 1:1
- Printing: Cat.6 U/UTP AWG24/7 stranded x 4pairs LSZH cable
- Silicone-free: True
- Suitable for degree of protection (IP): IP20
- Transmission: 5Gbit
- Type of connector connection 1: RJ45 8(8)
- Type of connector connection 2: RJ45 8(8)
Тегло, кг | 0.000000 |
---|---|
Марка | EFB Elektronik |
Цвят | Сив |
Екраниран | НЕ |
Екранировка | U/UTP |
Категория кабел | кат. 6 |
Вид конектор - КОМПЮТЪРЕН | RJ45 |
AWG-size | 24 |
Jacket type | LSZH |
Клас на защита | IP 20 |
Дълбочина, см | 0.000000 |
Ширина, см | 0.000000 |
Височина, см | 0.000000 |
