- Bandwidth: 100 MHz
- Category: 5e
- Color code: acc. TIA/EIA 568A/B
- Complaint to UL94: V-0
- Connection type: LSA
- Contact Resistance: 100 mΩ
- Cross section: AWG 24-AWG 22
- Current Rating: 1.5 A
- Depth: 108.0 mm
- Dielectric Withstanding Voltage: 750 V AC 60Hz
- Durability LSA contacts: 200
- Electrical strength: 125 V AC RMS
- Height: 44.0 mm
- Housing material LSA-terminal: PC
- Housing material Panel: Steel, 1.5 mm
- Housing material of RJ45 jacks: PBT
- Insertion force: 50 N
- Insulation Resistance: 1000 MΩ
- Material LSA contacts: Phosphor bronze, tinned
- Mating cycles RJ45 jack: 750
- Mounting method: Other
- Number of height units: 1U
- POE Standard: POE, POE+
- Suitable for number of connectors: 12
- Temperature Range (Operation): -10 – 60 °C
- Temperature Range (Storage): -40 – 70 °C
- Transmission: 2.5 Gbit
- Type of connector: RJ45 8(8)
- Width: 254.6 mm
- Screened: Yes
| Тегло, кг | 0.000000 |
|---|---|
| Марка | EFB Elektronik |
| Цвят | Сив |
| Височина, U | 1 |
| Екраниран | ДА |
| Категория кабел | кат. 5e |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
