- AWG-size: 24/7
- Allocation: acc. TIA/EIA 568B
- Anti-kink sleeve: moulded-on
- Area of Application: Data center, Industrial Ethernet, Structured cabling
- Bandwidth: 100MHz
- Bending radius: 27 mm
- Cable construction: 4x2
- Cable type: U/UTP
- Cabling standard: EN50173, ISO/IEC 11801
- Category: 5e
- Colour anti-kink sleeve: magenta
- Colour outer sheath: magenta
- Conductor Material: CCA
- Connector: IEC 60603-7-2
- Connector type: RJ45 standard
- Contact Resistance: < 20 mΩ
- Contacts: Gold plated µ" gold plated
- Current Rating: max. 1 A
- Fire retardant version: Yes
- Halogen free: No
- Length imprint: Yes
- Locking lever: No
- Material outer sheath: PVC
- Mating cycles: ≥750
- Model: Unshielded
- NVP value: - %
- Oil resistant (acc. EN 60811-2-1): No
- Oil resistant (according to EN 60811-404): No
- Operating-/tempering voltage: max. 50 V DC
- Outer diameter of the cable: 5.4 mm
- POE class: 4PPoE acc. to IEEE802.3bt, PoE+ acc. to IEEE802.3at, PoE acc. to IEEE802.3af
- Pin assignment: 1:1
- Printing: UTP Cat.5E 100MHZ 24AWGX4P Patch ISO/IEC 11801 & EN 50173 verified
- Silicone-free: Yes
- Suitable for degree of protection (IP): IP20
- Temperature range: 0 – 60 °C
- Transmission: 2.5Gbit
- Type of connector connection 1: RJ45 8(8)
- Type of connector connection 2: RJ45 8(8)
| Тегло, кг | 0.000000 |
|---|---|
| Марка | EFB Elektronik |
| Цвят | Розов |
| Екраниран | НЕ |
| Екранировка | U/UTP |
| Категория кабел | кат. 5e |
| Вид конектор - КОМПЮТЪРЕН | RJ45 |
| AWG-size | 24 |
| Jacket type | PVC |
| Клас на защита | IP 20 |
| EAN | 4049759031947 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
