Features
- Up to 48 fibers in 1RU
- Multiple Adaptor options available
- 24 adapter positions
- Recessed Adaptor positioning
- Individually labeled ports
- 45° open working angle
- Accepts loose tube, distribution and pre terminated cables
- RoHS and REACH SvHC
- Fits standard 19"
Applications
- Data centers, premise installations, telecommunication networks
- Ethernet, Fiber Channel, ATM, LAN, MAN and WAN
- Data communication
- Indoor applications
Specifications
- U Size: 1RU (44.4 mm)
- Width: 482 mm
- Depth: 205 mm
- Net weight: 2.5 kg
- Packaged weight: 3 kg
- Packaged dimensions: 530 mm W x 55 mm H x 260 mm D
- IP rating: IP20
- Suitable for Adaptor type: SC Simplex, LC Duplex, E2000
- Number of ports: 24
- Cable Entry 20 mm: 2
- Cable entry 25 mm: 2
- Mounting Adjustment range: 50 mm
- Material: Cold- rolled steel
- Material thickness: 1.2 mm
- Material coating: Powder coating
- Color: RAL 9004
- Operating temperature: -40°C to +50°C
- Designed in accordance with: TIA/EIA 568.C, ISO/IEC 11801, EN50173, IEC60304, IEC61754,
- Materials compliant to: RoHS, Reach/SVHC
| Тегло, кг | 0.000000 |
|---|---|
| Марка | FibreFab/ AFL Hyperscale |
| Цвят | Черен |
| Country of Manufacture | Китай |
| Брой адаптери | 24 |
| Височина, U | 1 RU |
| Клас на защита | IP 20 |
| Вид конектор - ОПТИЧЕН | E2000, LC, SC |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
