- AWG-size: 23/1
- Bending radius (dynamic): ≥ 80 mm
- Bending radius (static): ≥ 40 mm
- Cable: EN 50288-4-1, IEC 61156-5
- Cable Construction: S/FTP
- Cabling standards: EN 50173-1, EN 50288-4-1, IEC 61156-5, ISO/IEC 11801
- Capacity to earth: nom. 43 nF/km
- Category: 7
- Characteristic impedance: 100 ± 25 Ohm
- Conductor category: Kl.1 = single wire
- Conductor material: CU, tinned
- Core identification: color
- Core insulation: foam-skin PE
- Coupling attenuation: ≥ 85 dB
- Delay skew: ≤ 12 ns/100m
- Diameter conductor: 0.56 mm
- Flame retardant: No
- Halogen free (acc. EN 50267-2-2): No
- Halogen free (according to EN 60754-1/2): No
- Harmonized Standard: EN 50575
- Installation standard: EN 50174
- Insulation resistance (500V): ≥ 5000 MOhm/km
- Loop resistance: ≤ 165 Ohm/km
- Low smoke (according to EN 61034-2): No
- Material outer sheath: Polyethylene (PE)
- Max. Frequency: 900 MHz
- NVP value: 79 %
- Nominal cross section conductor: 0.26 mm²
- Permitted cable outer temperature after assembling without vibration: -55 – 60 °C
- Permitted cable outer temperature during assembling/handling: -20 – 50 °C
- PoE: acc. to IEEE802.3af PoE, acc. to IEEE802.3at PoE+, yes
- Resistance unbalance: ≤ 2 %
- Screen over stranding: braiding
- Screen over stranding element: foil + braid
- Separation class acc. EN50174-2: D
- Stranding element: Pairs
- Test voltage DC, 1 min: 1000 V
- Transfer impedance at 1MHz: ≤ 10 mOhm/m
- Transfer impedance at 10MHz: ≤ 10 mOhm/m
- Transfer impedance at 30MHz: ≤ 30 mOhm/m
- Transfer impedance at 100MHz: ≤ 60 mOhm/m
- Transmission standards: IEEE 802.3 10Mbit to 10Gbit
- UV resistance: Yes
| Тегло, кг | 0.000000 |
|---|---|
| Марка | EFB Elektronik |
| Цвят | Черен |
| Брой на жилата | 8 |
| Екраниран | ДА |
| Екранировка | S/FTP |
| Категория кабел | кат. 7 |
| AWG-size | 23 |
| Jacket type | PE |
| Сечение на проводника, mm2 | 0.26 |
| Дължина на кабела | 500 м |
| EAN | 8430220403701 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
