- AWG-size: 27/7
- Allocation: acc. TIA/EIA 568B
- Anti-kink sleeve: plugged in
- Area of Application: Data center, Industrial Ethernet, Structured cabling
- Bandwidth: 500MHz
- Bending radius: >30 mm
- Cable construction: 4x2
- Cable type: S/FTP
- Category: 6A (TIA)
- Colour anti-kink sleeve: violet
- Colour outer sheath: violet
- Conductive shield: Selected shield contact
- Conductor Material: Copper
- Conductor resistance DC: 185 Ω/km
- Connector: IEC 60603-7-51
- Connector type: RJ45 Standard green
- Contact Resistance: 30 mΩ
- Contacts: Gold plated
- Current Rating: max. 1 A
- Fire retardant version: Yes
- Flame retardant: Yes
- Halogen-free: Yes
- Halogen free: Yes
- Impedance: 100 ±15 Ω
- Insulation Resistance: 10 MΩ
- Length imprint: Yes
- Locking lever: Yes
- Loop resistance: 370 Ω/km
- Low smoke: Yes
- Material outer sheath: LSZH
- Mating cycles: 2000
- Model: Shielded
- NVP value: 74%
- Oil resistant (acc. EN 60811-2-1): No
- Oil resistant (according to EN 60811-404): No
- Operating-/ tempering voltage: max. 50 V DC
- Outer diameter of the cable: 6.0 mm
- POE class: 4PPoE acc. to IEEE802.3bt, PoE+ acc. to IEEE802.3at, PoE acc. to IEEE802.3af
- Pin assignment: 1:1
- Printing: Cat.6A PATCH S/FTP 4x2xAWG27/7 LSZH ISO/IEC11801 ANSI/TIA-568-C.2 ***10Gigabit Ethernet***
- Raw cable: Cat. 6A
- Resistance unbalance: 3%
- Silicone-free: Yes
- Suitable for degree of protection (IP): IP20
- Temperature range: -20 – 60 °C
- Test voltage: 1000 V DC, 1min
- Total screening: 80%
- Transmission: 10Gbit
- Type of connector connection 1: RJ45 8(8)
- Type of connector connection 2: RJ45 8(8)
- UL approbated: No
| Тегло, кг | 0.000000 |
|---|---|
| Марка | EFB Elektronik |
| Цвят | Виолетов |
| Екраниран | ДА |
| Екранировка | S/FTP |
| Категория кабел | кат. 6a |
| Вид конектор - КОМПЮТЪРЕН | RJ45 |
| AWG-size | 27 |
| Jacket type | LSZH |
| Клас на защита | IP 20 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
