- 4PPOE certified: Yes
- 360° shield contact: Yes
- AWG-range: 26 – 22
- AWG-range for litz wire conductor: 26 – 24
- Category: 6A (IEC)
- Complaint to UL94: V-0
- Connection type: Insulation displacement connector
- Contact Resistance: ≤ 20 mΩ
- Contact coating: 50 µ"
- Current Rating: 2 A
- Dielectric Withstanding Voltage: 1000 V AC 60Hz
- Dust cover: Yes
- For UAE suitable: No
- Housing material: Zinc die cast
- Insulation Resistance: ≥ 500 MΩ
- Mating cycles: ≥ 750
- Max. cable diameter: 9.0 mm
- Model: jack
- Special tool necessary: No
- Suitable for flat cable: No
- Suitable for litz wire conductor: Yes
- Suitable for round cable: Yes
- Suitable for solid core: Yes
- Temperature range: -40 – 66 °C
- Type of connector: RJ45 8(8)
- Screened: Yes
| Тегло, кг | 0.000000 |
|---|---|
| Марка | EFB Elektronik |
| Country of Manufacture | Китай |
| Екраниран | ДА |
| Категория кабел | кат. 6a |
| AWG-size | 26 |
| EAN | 4049759022242 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
