Ethernet Interface
- 10/100BaseT(X) Ports (RJ45 connector): Auto MDI/MDI-X connection
- Magnetic Isolation Protection: 1.5 kV (built-in)
Ethernet Software Features
- Industrial Protocols: Modbus TCP Client (Master), Modbus TCP Server (Slave)
- Configuration Options: Web Console (HTTP), Device Search Utility (DSU), MGate Manager, MCC Tool, Telnet Console
- Management: ARP, DHCP Client, DNS, HTTP, SNMPv1/v2c/v3, TCP/IP, Telnet, UDP
- MIB: RFC1213, RFC1317
Security Functions
- Authentication: Local database
- Encryption: HTTPS, AES-128, AES-256, SHA-256
Serial Interface
- No. of Ports: 1
- Connector: DB9 male
- Serial Standards: RS-232/422/485 (software selectable)
- Baud rate: 50 bps to 921.6 kbps
- Data Bits: 7, 8
- Parity: None, Even, Odd, Space, Mark
- Stop Bits: 1, 2
- Flow Control: DTR/DSR, RTS Toggle (RS-232 only), RTS/CTS
- RS-
| Тегло, кг | 0.000000 |
|---|---|
| Марка | Moxa |
| Цвят | Черен |
| Брой портове | 1 |
| Вид конектор - КОМПЮТЪРЕН | DB9 |
| Приложение: | Industrial |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
