Power Parameters
- Input Voltage: 100 to 240 VAC
- No. of Power Inputs: 2
- Overload Current Protection: Supported
- Power Consumption: 1.5 A @ 100 to 240 VAC
Physical Characteristics
- Dimensions: 440 x 260 x 88 mm
- Installation: 19-inch rack mounting
- IP Rating: IP30
- Weight: 5200 g
Environmental Limits
- Ambient Relative Humidity: 5 to 95% (non-condensing)
- Operating Temperature: 0 to 60°C
- Storage Temperature (package included): -20 to 75°C
Standards and Certifications
- EMC: EN 55032/35
- EMI: CISPR 32, FCC Part 15B Class A
- EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m, IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV, IEC 61000-4-5 Surge: Power: 2 kV(AC), 1 kV(DC), IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m, IEC 61000-4-8 PFMF
- Environmental Testing: IEC 60068-2-1, IEC 60
| Тегло, кг | 0.000000 |
|---|---|
| Марка | Moxa |
| Цвят | Черен |
| Височина, U | 2 |
| Form Factor | Rack mount |
| Клас на защита | IP 30 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
