Serial Interface
- Comm. Controller: 16C550C compatible
- Bus: PCI Express 1.0
- Connector: DB44 female
- FIFO: 128 bytes
- Max. No. of Boards per PC: 8
- No. of Ports: 4
- Serial Standards: RS-232, RS-422, RS-485
- Baud rate: 50 bps to 921.6 kbps (supports non-standard baudrates)
- Data Bits: 5, 6, 7, 8
- Stop Bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow Control: None, RTS/CTS, XON/XOFF
Serial Signals
- RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- RS-422: Tx+, Tx-, Rx+, Rx-, GND
- RS-485-4w: Tx+, Tx-, Rx+, Rx-, GND
- RS-485-2w: Data+, Data-, GND
Serial Software Features
- Windows Drivers: DOS, Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1/10 (x86/x64), Windows 2008 R2/2012/2012 R2/2016/2019 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded
- Linux Drivers: Linux kernel 2.4.x, Linux kernel 2.6.x, Linux
| Тегло, кг | 0.000000 |
|---|---|
| Марка | Moxa |
| Брой портове | 4 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
