Interface
- 1-port 10/100Base-T RJ-45 with auto negotiation and auto-MDI/MDI-X function
- 1 Mini-GBIC slot, providing multi choice of SFP modules
Industrial Conformance
- 12V to 48V DC, redundant power with polarity reverse protect function
- -40 to 75 degrees C operating temperature
- IP30 metal case
- Relay alarm for port breakdown
- Supports 6KV DC Ethernet ESD protection
- Supports 6KV DC EFT protection for power line
- Free Fall, Shock and Vibration Stability
- DIN-rail and wall-mountable hardware design
Layer 2 Features
- Complies with the IEEE 802.3, IEEE 802.3u Fast Ethernet standard
- Auto-MDI / MDI-X detection and auto negotiation in half-duplex / full-duplex modes for 10 /100Base-TX RJ-45 port
- Store-and-Forward Switching Architecture
- Features Store-and-Forward mode with wire-speed filtering and forwarding rates
- Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
- Supports packet size of up to 1522bytes
- CSMA/CD Protocol
- Automatic source address learning and aging
| Тегло, кг | 0.000000 |
|---|---|
| Марка | Planet - Тайван |
| Цвят | Син |
| Country of Manufacture | Тайван |
| Form Factor | За монтаж на DIN шина |
| Приложение: | Industrial |
| Клас на защита | IP 30 |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
