2.5mm universal connector, for 1.25mm connectors, FC (Male)-LC (Female)
Convertor can be provided on requests.
Operates either in CW or Pulsed
Constant output power
Lower Battery warning
Long battery life (up to 60 hours)
Crash-proof and dust-proof design for laser head
Laser case ground design prevents ESD damage
Burning testing to ensure the reliability.
Portable and rugged, easy to use
Specifications
Central Wavelength - 650nm±10nm
Emitter Type - FP-LD
Output Power - Optional choice for 1mw, 10mw on actual needs
Optical Connector - 2.5mm universal connector
Operating Model - Both CW and Pulse available
Pulse Frequency - 2~3Hz
Power Supply - 2 AA alkaline batteries
Battery Operating Time - 650nm@1mw ≥65hour, 650nm@10mw≥15hour, Test with Panasonic LR6 AA ALKALINE battery
Operating Temperature - -10~+45 (℃)
Storage Temperature - -40~+70 (℃)
Dimension - 24.5*5.5*5.5cm
Weight - 0.2kg
| Тегло, кг | 0.000000 |
|---|---|
| Марка | Joinwit |
| Country of Manufacture | Китай |
| Дълбочина, см | 0.000000 |
| Ширина, см | 0.000000 |
| Височина, см | 0.000000 |
