Technical Specification
Optical Power Meter
Wavelength range - 800~1700nm
Optical detector - InGaAs
Interface type - 2.5 Universal Connector
Power measurement range - -70~+6dBm or -50~+26dBm
Uncertainty - ±5%
Standard wavelength - 850/1270/1300/1310/1490/1550/1577/1625nm
Display resolution - Log display：0.01dBm
Recognizable frequency - 270Hz、1KHz、2KHz
Visual Fault Locator
Operating wavelength - 650nm
Output power - 15mW
Working mode - CW/2Hz
Interface type - 2.5 Universal Connector
RJ45 Sequence
Test mode - Test the sequence of network cables
Other
Power supply - 2 AAA batteries/Optional lithium batteries，3.7V/800mAh
Port - Type C
Automatic shutdown time - 10min
Operating temperature - -10℃~+50℃
Storage temperature - -40℃~+70℃
Relative temperature - 0~95%RH
Dimension - 110*68*30mm
Weight - 140g
