Ethernet Intefaces:
- 10/100BaseT(X) Ports (RJ45 connector) - 8
- Full/Half duplex mode
- Auto MDI/MDI-X connection
- Auto negotiation speed
Standards:
- IEEE 802.3 for 10BaseT
- IEEE 802.1p for Class of Service
- IEEE 802.3u for 100BaseT(X)
- IEEE 802.3x for flow control
Switch Properties
- Processing Type - Store and Forward
- MAC Table Size - 2 K
- Packet Buffer Size - 768 kbits
DIP Switch Configuration
Ethernet Interface - Quality of Service (QoS) , Broadcast Storm Protection (BSP)
Power Parameters
- Connection - 1 removable 3-contact terminal block(s)
- Input Current - 0.057 A @ 24 VDC
- Input Voltage - 12-48 VDC
- Operating Voltage - 9.6 to 60 VDC
- Overload Current Protection - Supported
- Reverse Polarity Protection - Supported
Physical Characteristics
- Dimensions - 36 x 81 x 65 mm (1.4 x 3.19 x 2.56 in)
- Installation - DIN-rail mounting, Wall mounting (with optional kit)
- Housing - Plastic
- Weight - 110.5 g (0.24 lb)
| Тегло, кг | 0.130000 |
|---|---|
| Марка | Moxa |
| Цвят | Черен |
| Country of Manufacture | Тайван |
| Вид Лан Портове | 10/100 Mb/s RJ45 |
| Брой Лан Портове | 8 |
| Оптични портове | НЕ |
| Брой Оптични Портове | 0 |
| PoE | НЕ |
| PoE Стандарт | Няма |
| Приложение: | Industrial |
| Управление на суичовете | Неуправляем |
| Form Factor | За монтаж на DIN шина |
