Cold-rolled steel of thickness: 1.5 mm
Load capacity to 100 kg
Available in black RAL9004
Assembly instructions: fixed-mounted to rack rails
Compatible with NCB cabinets of 800 mm in depth
Surface finish: degreasing, etching, phosphating, powder coating
Protection against rust, oxidation, scratches, corrosion
Compliant with ANSI/EIA RS-310-D, DIN41491 PART1, IEC297-2, DIN41494 PART7, GB/T3047.2-92
Compatible with metric ETSI and 19-inch international standards
| Shelf type | Fixed |
|---|---|
| Compatible with | NCB cabinets of 800 mm in depth |
| Mounting | Four points to the rack rails |
| Dimensional depth | 550 mm |
| Usable depth | 550 mm |
| Dimensional width | 471 mm |
| Usable width | 471 mm |
| Height | 31.5 mm |
| Maximum load capacity | 100 kg |
| Steel thickness | 1.5 mm |
| Color | Black RAL9004 |
| Additional information |
- Cold-rolled steel |
| Net weight | 2 kg |
| Weight, kg | 3.100000 |
|---|---|
| Brand | Linkbasic |
| Color | Black |
| Country of Manufacture | China |
| Loading capacity kg | 100 |
| Depth, mm | 800 |
| Depth, cm | 0.000000 |
| Width, cm | 0.000000 |
| Height, cm | 0.000000 |
