USB Interface
- Speed: 12 Mbps
- USB Connector: USB Type A
- USB Standards: USB 2.0 compatible, USB 1.0/1.1 compliant
Serial Interface
- No. of Ports: 1
- Connector: DB9 male
- Baud rate: 50 bps to 921.6 kbps
- Data Bits: 5, 6, 7, 8
- Stop Bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow Control: None, RTS/CTS, XON/XOFF
- Serial Standards: RS-422/485
Serial Signals
- RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- RS-422: Tx+, Tx-, Rx+, Rx-, GND
- RS-485-4w: Tx+, Tx-, Rx+, Rx-, GND
- RS-485-2w: Data+, Data-, GND
Serial Software Features
- Windows Drivers: Windows 11, 10, 8.1, 8, 7, Vista, ME and XP
- Windows Server: 2022, 2019, 2016, 2012 R2, 2012, 2008 R2, 2008, 2003, 2000 and NT
- Linux Drivers: Kernel 6.x, 5.x, 4.x, 3.x, 2.6.x and 2.4.x
- Mac Drivers: macOS 10.12 to 10.15
- Arm®-based Platform
Weight, kg | 0.000000 |
---|---|
Brand | Moxa |
Color | White |
Number of ports | 1 |
Standard | USB 1.1, USB 2.0 |
Connector type | USB Type-A, DB9 |
Depth, cm | 0.000000 |
Width, cm | 0.000000 |
Height, cm | 0.000000 |
