General Specifications
- Category: 6A
- Cable Type: S/FTP (shielded)
- Conductor Type: Stranded
- Interface, Connector A: RJ45 plug
- Interface Feature, connector A: Standard
- Interface, Connector B: RJ45 plug
- Interface Feature, connector B: Standard
- Jacket Color: White | Black | Blue | Green | Orange | Pink | Purple | Red | Slate | Violet | Yellow
- Pairs, quantity: 4
- Transmission Standards: IEEE 802.3bt Type 4
- Wiring: T568B
Dimensions
- Cable Assembly Length Range (m): 1 – 30
- Cable Assembly Length Range (ft): 1 – 100
- Cable Assembly Length Range (cm): 15 – 999
- Cable Assembly Length Range (in): 6 – 999
- Diameter Over Jacket: 5.84 mm | 0.230 in
- Compatible Conductor Gauge, stranded: 26 AWG
Electrical Specifications
- Safety Voltage Rating: 300 V
Mechanical Specifications
- Plug Insertion Life, minimum: 750 times
Environmental Specifications
- Operating Temperature: -20 °C to +60 °C (-4 °F to +140 °F)
- Relative Humidity: Up to 93%, non-condensing
- Environmental Space: Low Smoke Zero Halogen (LSZH)
- Safety Standard: UL 1863
Packaging and Weights
- Packaging quantity: 1
Regulatory Compliance/Certifications
- RCM: Compliant to electrical safety & telecommunications requirements
| Weight, kg | 0.000000 |
|---|---|
| Brand | COMMSCOPE |
| Depth, cm | 0.000000 |
| Width, cm | 0.000000 |
| Height, cm | 0.000000 |
